Classic Die Tools Setup

OUR SHOP FLOOROUR SHOP FLOOR
• 6000 Square Feet Slab Constructed Shop   Floor Area.
• 800 Square Feet office Area
• 200 Square Feet Design Office
• 100 Sq. Ft. Quality Control Office with all
  measuring Instruments
• 500 Square Feet Parking Area
• 67 HP Power
• 5 Ton Capacity Fully Automatic Over head
  Crane
• 2 Ton Capacity Gantry Crane
• 2 Ton Capacity Hydraulic Stacker

OUR DESIGN DEPARTMENTOUR DESIGN DEPARTMENT
• UNIGRAPHICS NX9 Full Featured CAD
  Software
• UNIGRAPHICS NX12 Full Featured CAD
  Software
• WORK NC Full Featured CAM Software
• WORK EXPLORE CAD Viewer Software
• CADBRO Cad Viewer Software
• ZW2D Software
• SIMULATION Software facility is available
  at our vendor end
• Qualified and Experienced Design and
  CAM Engineers

OUR QUALITY CONTROL DEPARTMENTOUR QUALITY CONTROL DEPARTMENT
• 1000X650X150 LUTHRA Make Granite
  Surface Plate
• 0-600mm Digital Height Gauge
  (Baker Make)
• 0-300 Vernier Calipers (Digital+Normal)
• 0-25, 25-50, 50-75, 75-100, outside
  Micrometers (Baker Make)
• 10-18, 18-50, 50-150, Dial Bore Gauge
  (Baker Make)
• 0-300 mm scale
• 0-1000 mm scale
• Plunger Dial
• Lever Dial
• Optical Edge Finder

VMC MACHINEVMC MACHINE 1
• Make :- Bharat Fritz Warner Ltd.
  Bangalore, India.
• Model :- BMV 65 SOORAJ
• Table Size :- 1500 x 650 x 700 mm
• Travels :- 1280 x 710 x 650 mm
• Max . Weight Carrying Capacity:- 2 Ton
• Controller:- Mitsubishi M70 A
• Spindle Taper:- BT 50
• RPM:- 6000
• Year Of Mfg.:- 2012



VMC MACHINEVMC MACHINE 2
• Make :- Bharat Fritz Warner Ltd.
  Bangalore, India.
• Model :- BMV 60 CHAKRA
• Table Size :- 1250 x 600 x 600 mm
• Travels :- 1250 x 610 x 600 mm
• Max . Weight Carrying Capacity:- 1.5 Ton.
• Controller:- Mitsubishi M70 A
• Spindle Taper:- BT 50
• RPM:- 6000
• Year Of Mfg.:- 2013



VMC MACHINEVMC MACHINE 3
• Make :- Bharat Fritz Warner Ltd.
  Bangalore, India.
• Model :- BMV 45 Agani
• Table Size :- 850 x 450 mm
• Travels :- 650 x 450 x 450 mm
• Max . Weight Carrying Capacity :- 600 Kg.
• Controller:- Mitsubishi M70 A
• Spindle Taper:- BT 40
• RPM:- 8000
• Year Of Mfg.:- 2015



CNC EDM MACHINECNC EDM MACHINE
• Make:- Agie Charmilles
• Model :- SP3U
• Tank Size :- 1250 x 700 x 420 mm
• Travels :- 500 x 400 x 400 mm
• Max . Weight Carrying Capacity:- 1 Ton
• Max Electrode Wt. :- 100 kg
• Max Amps. :- 100 Amps
• 17 inch Touch Screen Monitor
• Orbital Sparking Possible, Axis Sparking
  Possible
• Can Achieve any Ra Value Surface Finish
• Year Of Mfg.:- 2013

RADIAL DRILLING MACHINERADIAL DRILLING MACHINE
• Make:- FOSTER (Made in Taiwan)
• Model:- Z6030
• Arm Length :- 1500 mm
• Max Drill Dia :- 50 mm
• Auto feed available
• Hydraulic clamp/ declamp
• RPM:- 40 to 2000
• Feed Range :- 0.4 to 3.2
• Year Of Mfg.:- 2012















SURFACE GRINDING MACHINESURFACE GRINDING MACHINE
• Make:- ALPA ( Made in ITLY)
• Model:- RT 550
• Table Size :- 600 X300 mm
• Travels :- 600 x 300 x 400
• Max . Weight Carrying Capacity:- 600 kg.
• Wheel Width :- 40 mm
• Auto feed for all axis
• Year Of Mfg.:- 1997






PRICISION LATHE MACHINEPRICISION LATHE MACHINE
• Make:- Prateek ( Made in India)
• Table Size :- 6 feet
• Swing Over Bed:- 225 mm
• Medium Duty tool room Precision Lathe
• Year Of Mfg.:- 2012








AIR COMPRESSORAIR COMPRESSOR
• Make:-Atlas Copco
• Model:- GX 5P FF
• Tank Capacity :- 21 CFM
• Pressure :- 10 BAR
• Power :- 7.5 hp
• With Air Dryer
• Silent Noise SCREW compressor
• Year Of Mfg.:-2012
